TAG Tow Ball Mount – 210mm Long, 108° Face, 50mm Square Hitch

$55.00

SKU: L4006 Category:

Description

FEATURES:

TAG Tow Ball Mounts are manufactured using stainless steel, CNC milled and robotically welded for precision and consistency. Designed to accompany the TAG Heavy Duty Towbar, fitting a 50mm Square Hitch Receiver and available in multiple drop/rise or adjustable configurations. All TAG Tow Ball Mounts are ADR compliant, batch marked and powder-coated for a premium, durable finish.

  • 210mm Long (Hitch Pin Hole to Tow Ball Hole)
  • 108° Tongue Face
  • Drop: 105mm
  • Can be mounted in Drop Mode Only
  • 2700kg Gross Trailer Weight
  • 270kg Ball Weight
  • Durable Powder-Coated Finish
  • ADR 62/02 Compliant
  • TAG Limited Lifetime Warranty

Tow Ball, R-Clip & Hitch Pin sold separately.

TECHNICAL SPECS:

  • Tow Ball Mount Class: Heavy Duty (Class 4)
  • Gross Trailer Weight: 2700
  • Coating: Powder Coated
  • Rise: Cannot be used in Rise Mode
  • Drop: 105mm
  • Tongue Face: 108°
  • Ball Weight: 270

STOCK LEVELS MAY VARY. PLEASE CHECK BEFORE ORDERING.

Additional information

Weight 5 kg
Dimensions 25 × 10 × 10 cm
